Phaser 6500/WorkCentre 6505 Service Manual Xerox Internal Use Only 8-85
Service Parts Disassembly
The actuators for Registration In (the light gray one) and Manual Feed (the larger
black one) are now easily accessible.
s6500-501
s6500-502
Registration In Actuator
Manual Feed Actuator
