Phaser 6500/WorkCentre 6505 Service Manual Xerox Internal Use Only 8-157
Service Parts Disassembly
14. Pull the harness, power switch, and connector (J48) out through the hole in the
Inlet Chassis.
s6500-342
Latches
Latches
s6500-343
