Phaser 6500/WorkCentre 6505 Service Manual Xerox Internal Use Only 8-197
Service Parts Disassembly
13. Remove the clamp that secures the ADF Assembly harness to the chassis.
14. Remove the ferrite core from the ADF Assembly harness.
s6500-380
s6500-496
Ferrite Core
