9-6 Xerox Internal Use Only Phaser 6500/WorkCentre 6505 Service Manual
Parts Lists
SFP Parts List 1.1 Covers (1/2)
Item Description Part Number
1 Cover Assy Top (With 22-24) 848K52942
2 Tray Ext (Output Tray Extension) 050K66881
3 Cover Rear 848E61690
4—
5 Cover CST (Rear Tray Cover) 848E38130
6 Cover Side R 848E61650
7 Cover Assy Window TNR (Toner Door) 848K53091
8—
9—
10 —
11 —
12 —
13 —
14 —
15 —
16 —
17 —
18 —
19 Cover Side L 848E61660
20 —
21 —
22 Cover Top Sub
23 Cover Top Main
24 Guide Tray
25 —
