Xerox WorkCentre 6505 Service Manual

9-8 Xerox Internal Use Only Phaser 6500/WorkCentre 6505 Service Manual
Parts Lists
SFP Parts List 1.2 Covers (2/2)
Item Description Part Number
1 Cover Assy Front (with 2,3,5,10,11,28,29,32) 848K53921
2Cover Front Lower
3 Console Assy Panel (Control Panel) 848K53033
4—
5 Latch Assy Front (with 6-9)
6Latch Front L
7Latch Front Dup
8 Plate Latch
9Latch Front R
10 Spring Latch Front
11 Button Latch Front
12 Harness Assy A (J202-J5301) (Control Panel Harness) 962K73100
13 Harn Assy Dup Relay (J271-P272) 962K73400
14 Holder Front R
15 Cover Drawer
16 Bracket Holder R
17 Shaft Link Front
18 Link Assy Front
19 Holder Front L
20 Bracket Holder L
21 —
22 Harn Assy Gnd
23 Shaft Pivot
24 Spring Link Front
25 —
26 Shaft Link Front Fdr
27 —
28 Holder Assy Front R (with 13-18)
29 Holder Assy Front L (with 17-20, 22)
30 Cover Link Front
31 —
32 Cover Front Upper
96 Kit Shaft Link Front (with 17 x 2 pcs) (Upper) 604K53040
97 Kit Shaft Link Front FDR (with 26 x 2 pcs) (Lower) 604K53050
98 Kit Shaft Pivot (with 23 x 2 pcs) (Front Cover) 675K54051
