Xerox WorkCentre 6505 Service Manual

9-12 Xerox Internal Use Only Phaser 6500/WorkCentre 6505 Service Manual
Parts Lists
MFP Parts List 1.2 Covers (2/2)
Item Description Part Number
1 Cover Assy Front (with 2, 5, 10-12, 24,29) 848K51394
2Cover Front Lower
3 Console Assy Panel (Control Panel) 848K46336
4 Cover Inner Front
5 Latch Assy Front (with 6-9)
6Latch Front L
7Latch Front Dup
8 Plate Latch
9Latch Front R
10 Spring Latch Front
11 Button Latch Front
12 Holder Assy Front L (with 13-16, 27, 28)
13 Holder Front L
14 Shaft Pivot
15 Harness Assy Dup Gnd
16 Plate Earth
17 Holder Link Lower
18 Plate Link
19 Spring Link
20 —
21 Holder Link Upper
22 Pad L
23 Holder Slider
24 Holder Front R
25 Strap B
26 Strap A
27 Harness A-OP-OPP (J202-P5301) 962K73540
28 Link Assy Front AIO (with 17-19,21-23)
29 —
30 Strap Assy (with 25,26) 801K45121
31 Cover Front Upper)
32 Harn Assy Dup Relay (J271-P272)
99 Kit Shaft (14x2pcs) 675K54051
