Xerox WorkCentre 6505 Service Manual

9-22 Xerox Internal Use Only Phaser 6500/WorkCentre 6505 Service Manual
Parts Lists
Parts List 4.1 Xerographics
Item Description Part Number
1 ROS Assy (Laser Unit)
2Spring ROS
3Holder CRUM
4Spring PHD
5Lever PHD
6Block Stopper PHD D
7Block Stopper PHD AD
8 LED Assy Erase 122K94041
9 Spring Tracking
10 Spring CF
11 Spring TR4
12 Spring TR3
13 Spring TR2
14 Spring TR1
15 Spring D4
16 Spring D3
17 Spring D2
18 Spring D1
19 PWBA HVPS 105K24390
20 Frame HVPS (SFP only) 801E01504
21 Imaging Unit 676K05360
22 Harn Assy ROS RE (J40-J411)
23 Harn Assy ROS Video (J41-J412)
97 Kit Block PHD Right (with 4, 5, 7 x 2 pcs) 675K54241
98 Kit Block PHD Left (with 4, 5, 6 x 2 pcs) 675K54251
99 Kit ROS Assy (with 1, 2 x 2 pcs) (Laser Unit) 604K64550
http://www.manuals4you.com

Xerox WorkCentre 6505 Specifications

General

Print Technology	Laser
Copy Resolution	Up to 600 x 600 dpi
Standard Paper Capacity	250 sheets
ADF Capacity	35 sheets
Functions	Print, Copy, Scan, Fax
Processor	533 MHz
Memory	256 MB
Fax Transmission Speed	33.6 kbps
Monthly Duty Cycle	40, 000 pages
Connectivity	USB 2.0, Ethernet 10/100Base-TX
Maximum Paper Size	8.5 x 14 in
Operating System Compatibility	Windows, Mac, Linux
Print Resolution	Up to 1200 x 2400 dpi
