9-30 Xerox Internal Use Only Phaser 6500/WorkCentre 6505 Service Manual
Parts Lists
SFP Parts List 8.1 Electrical (1/2)
Item Description Part Number
1 Fan 127E86270
2Duct Fan
3 Shield Assy ESS
4—
5Frame ESS
6Plate IF
7 PWBA ESS (with 8) (IP Board) 960K56232
8NVM ROM
9—
10 —
11 —
12 Plate ESS
13 Screw Knurling
14 Washer
15 Memory Card (512 MB) 237E25990
16 —
17 —
18 —
19 —
