9-34 Xerox Internal Use Only Phaser 6500/WorkCentre 6505 Service Manual
Parts Lists
MFP Parts List 8.1 Electrical & Frame (1/4)
Item Description Part Number
1 Harn Assy Interlock AIO (SW-J44) 962K65360
2 PWBA ESS AIO (with 3) (MFP IP Board) 960K51502
3NVM ROM
4 Memory Card (Option) 237E25990
5 PWBA Fax 960K53600
6Cap Plug Rubber
7 Shield Assy ESS AIO (with 8,9)
8 Shield ESS AIO
9Cover Inner
10 Sensor HUM (Humidity Sensor) 130E93460
11 —
12 —
