Phaser 6500/WorkCentre 6505 Service Manual Xerox Internal Use Only 9-43

Parts Lists

Parts List 9.1 Harness

Item Description Part Number

1 SFP Harness Assy ESS (J10-J101)

MFP Harness Assy ESS (J10-J2001)

2 SFP Harness Assy ESS Video (J11-J111)

MFP Harness Assy ESS Video (J11-J2002)

3 SFP Harness Assy LVPS2 (J14, J15-J141, J501, J502)

MFP Harness Assy LVPS Main (J14, J15, P5041-J141,

J501, J502, J504)

4—

5 Harness Assy HVPS (J16-J161)

6 Harness Assy Humidity (J20-J201) (SFP only)

7 Harness Assy Main Motor (J21-J211)

8 Harness Assy Sub Motor (J22-J221)

9 Harness Assy KSNR Regcl (J26-J261,P262)

10 SFP Harness Assy ESS Power (J40-J401)

MFP Harness Assy ESS Power (J40-J802)

11 Harness Assy PHD XPRO (J42-J144,P422) 962K52000

12 SFP Harness Assy B (J29-P5301)

MFP Harness Assy A-OP-ESS (J403-P5301)

13 —
