Xerox WorkCentre 6505 Service Manual

Phaser 6500/WorkCentre 6505 Service Manual Xerox Internal Use Only 9-45
Parts Lists
PL10.1 Scanner Assy
Item
Description Part Number
1 Scanner Assy (with 2,3,11)
2 Harn Assy ADF (J1003-JADF1)
3 ADF Assy (with 4-10)
4Cover Top ADF
5 Roll Assy Feed
6 Pad Assy Separator
7 Cover Assy Rear ADF
8 Tray Assy 050K63721
9 Counter Balance L
10 Counter Balance R
11 IIT Assy Sub (IIT Subassembly) 604K66320
12 Core Ferr FFC 121E22020
13 Harness Assy Front USB (J2-J1301)
14 Bracket Assy USB (with 15,16)
15 PWB Assy Front USB
16 Bracket Front USB
95 Kit PWB Assy Front USB (with 13,14) 675K99680
96 —
97 Kit ADF Assy (with 2,3) 675K99690
98 ADF Feed Roll & Separator Roll Kit (with 5-6, Instruction) 604K52222
99 Kit Counter Balance (with 9,10) 604K49540

Xerox WorkCentre 6505 Specifications

General

Print Technology	Laser
Copy Resolution	Up to 600 x 600 dpi
Standard Paper Capacity	250 sheets
ADF Capacity	35 sheets
Functions	Print, Copy, Scan, Fax
Processor	533 MHz
Memory	256 MB
Fax Transmission Speed	33.6 kbps
Monthly Duty Cycle	40, 000 pages
Connectivity	USB 2.0, Ethernet 10/100Base-TX
Maximum Paper Size	8.5 x 14 in
Operating System Compatibility	Windows, Mac, Linux
Print Resolution	Up to 1200 x 2400 dpi
