Phaser 6500/WorkCentre 6505 Service Manual Xerox Internal Use Only 9-47
Parts Lists
Parts List 11.1 Duplex Unit (1/2)
Item Description Part Number
1 Feeder Assy Dup (With 2-16, PL11.2) 059K65450
2Chute Dup In
3 Spring Pinch Dup
4 Roll Pinch Dup
5 Spring Latch Dup
6Latch Dup
7 Follower Latch Dup (SFP only)
8Holder Chute Dup
9Spring Chute Dup
10 Holder Harness Dup
11 Cover Connect Dup (SFP only)
12 Spring Connect Dup (SFP only)
13 Holder Connect Dup (SFP only)
14 Harness Assy Dup (J272-J601) 962K68790
15 Cover PWBA Dup
16 PWBA Dup 960K43081

Xerox WorkCentre 6505 Specifications

General

Print Technology	Laser
Copy Resolution	Up to 600 x 600 dpi
Standard Paper Capacity	250 sheets
ADF Capacity	35 sheets
Functions	Print, Copy, Scan, Fax
Processor	533 MHz
Memory	256 MB
Fax Transmission Speed	33.6 kbps
Monthly Duty Cycle	40, 000 pages
Connectivity	USB 2.0, Ethernet 10/100Base-TX
Maximum Paper Size	8.5 x 14 in
Operating System Compatibility	Windows, Mac, Linux
Print Resolution	Up to 1200 x 2400 dpi
