Xerox WorkCentre 6505 Service Manual

9-54 Xerox Internal Use Only Phaser 6500/WorkCentre 6505 Service Manual
Parts Lists
Parts List 12.2 Optional Feeder (2/5)
Item Description Part Number
1 SFP PWBA Feed (Optional Feeder Board)
MFP PWBA Feed (Optional Feeder Board)
960K43091
960K54130
2 Harn Assy Tray Mot (J422-J211)
3—
4—
5—
6 Clutch Assy Drv (with PL12.3.16) (Same as PL3.1.97) 675K54231
7—
8 Spring Feed Out (Same as PL3.1.15)
9 Spring Feed In (Same as PL3.1.14)
10 Gear Assy Feed (With 11,12) (Same as PL3.1.19)
11 Gear Feed Out (Same as PL3.1.16)
12 Gear Feed In (Same as PL3.1.17)
13 Lever Feed (Same as PL3.1.13)
14 Spring Lever (Same as PL3.1.12)
15 Solenoid Feed MSI (Same as PL3.1.11)
16 Motor Assy Sub
17 Gear Idle 40z
18 Gear Idle 86-20z
19 Plate Assy Idler 1
20 Harn Assy Tray Comp (J420, J421-P4201. J4202,
J4212, P4213)
21 Cover Harness CL
22 Plate Assy Idler 2
23 Gear Idle 36z
24 Gear Idle 28-20z
25 Gear Idle 22-33z
26 Gear Idle 25z
27 Plate Support
97 Kit Solenoid Feed (with 8-10, 13-15) 604K51880
98 Kit Assy Motor Opt (with 16-18) (Feed Motor Kit) 604K52890
99 Kit Assy Feeder Gear (with 21-25, 26 x 2pcs, 27) 604K51900
http://www.manuals4you.com

Xerox WorkCentre 6505 Specifications

General

Print Technology	Laser
Copy Resolution	Up to 600 x 600 dpi
Standard Paper Capacity	250 sheets
ADF Capacity	35 sheets
Functions	Print, Copy, Scan, Fax
Processor	533 MHz
Memory	256 MB
Fax Transmission Speed	33.6 kbps
Monthly Duty Cycle	40, 000 pages
Connectivity	USB 2.0, Ethernet 10/100Base-TX
Maximum Paper Size	8.5 x 14 in
Operating System Compatibility	Windows, Mac, Linux
Print Resolution	Up to 1200 x 2400 dpi
