Xerox WorkCentre 6505 Service Manual

9-58 Xerox Internal Use Only Phaser 6500/WorkCentre 6505 Service Manual
Parts Lists
Parts List 12.4 Optional Feeder (4/5)
Item Description Part Number
1 Chute Assy Turn (With 2-13, 16, 20-27, 29-33)
2 Shaft Assy Feed
3 Roll Core MSI
4 Roll Assy Feed 059K60140
5Bearing Earth
6Actuator Regi Out
7 Spring Regi Out
8Actuator Regi Roll
9 Roll Assy Regi
10 Roll Regi Metal
11 Actuator Regi In (Option Registration Input Actuator) 120E27820
12 Spring Act Regi
13 Sensor Photo 930W00113
14 —
15 —
16 Spring Stp
17 Stopper Act
18 Spring Act NP
19 Actuator No Paper
20 Bearing M Earth
21 Bearing Earth Regi
22 Gear Regi R
23 Gear Regi M
24 Spring Regi R M
25 Plate Earth Regi
26 Chute Up
27 Chute Low
28 —
29 Spring Regi L M
30 Bearing M
31 Bearing R
32 Actuator Assy No Paper (With 17-19) 120K92294
33 Plate Weight
http://www.manuals4you.com

Xerox WorkCentre 6505 Specifications

General

Print Technology	Laser
Copy Resolution	Up to 600 x 600 dpi
Standard Paper Capacity	250 sheets
ADF Capacity	35 sheets
Functions	Print, Copy, Scan, Fax
Processor	533 MHz
Memory	256 MB
Fax Transmission Speed	33.6 kbps
Monthly Duty Cycle	40, 000 pages
Connectivity	USB 2.0, Ethernet 10/100Base-TX
Maximum Paper Size	8.5 x 14 in
Operating System Compatibility	Windows, Mac, Linux
Print Resolution	Up to 1200 x 2400 dpi
