Xerox WorkCentre 6505 Service Manual

9-60 Xerox Internal Use Only Phaser 6500/WorkCentre 6505 Service Manual
Parts Lists
Parts List 12.5 Optional Feeder (5/5)
Item Description Part Number
1 Cassette Assy 250 Opt (With 19,21) 050K64180
2 Plate Assy Bottom
3Spring N/F L
4Spring N/F R
5 Holder Assy Separator 675K81221
6 Guide Side L
7Gear Pinion
8 Guide Side Assy R
9—
10 —
11 —
12 —
13 —
14 Latch Bottom L
15 Latch Bottom R
16 Spring Latch B
17 Tray Assy Extension
18 Housing CST 250
19 Handle Assy CST 250 Opt
20 —
21 Tray Assy CST 250 (With 2-8, 14-18)
http://www.manuals4you.com

Xerox WorkCentre 6505 Specifications

General

Print Technology	Laser
Copy Resolution	Up to 600 x 600 dpi
Standard Paper Capacity	250 sheets
ADF Capacity	35 sheets
Functions	Print, Copy, Scan, Fax
Processor	533 MHz
Memory	256 MB
Fax Transmission Speed	33.6 kbps
Monthly Duty Cycle	40, 000 pages
Connectivity	USB 2.0, Ethernet 10/100Base-TX
Maximum Paper Size	8.5 x 14 in
Operating System Compatibility	Windows, Mac, Linux
Print Resolution	Up to 1200 x 2400 dpi
