Configuring Display Settings
• Setting the Layout of Windows and Graphs
• Configuring Trace Display Settings
• Setting Display Color
Other topics about Setting up Analyzer
Setting the Layout of Windows and Graphs
You can split the E5071C's LCD screen into multiple windows that display
channel-specific result information, and the window layout can be selected
from a number of variations. In addition, you can place on screen a
segment sweep table or echo window, which you can use to display
messages from your custom program.
Selecting the window layout (Channel Display Mode)
One window displays the results for a single channel. You cannot have a
single window display the results from more than one channel. This means
that setting the window layout determines the number of channels
displayed on screen.
To select one of the 19 different window layouts shown in the figure below,
use the following command:
:DISP:SPL
Selecting the graph layout (Trace Display Mode)
You can place a number of trace graphs in each window by selecting one of
the pre-defined graph layouts. The number of graphs differs depending on
your selected graph layout. If the number of graphs is equal to or larger
than the number of traces (set by the :CALC{1-36}:PAR:COUN command),
each graph always displays one trace. On the other hand, if the number of
graphs is smaller than the number of traces, some of the graphs display
two or more traces. Graph 1 is populated with trace 1, graph 2 with trace
2, and so on. Traces whose numbers exceed the last graph's number will
populate graph 1, graph 2, and so on.
To select one of the 19 different graph layouts shown in the figure below,
use the following command:
:DISP:WIND{1-36}:SPL
Maximizing a window or a trace graph
When you have multiple windows displayed, you can maximize the active
channel window so that it covers the entire screen area. To maximize a
window, use the following command:
