Epson Stylus Pro 4900/Epson Stylus Pro 4910 Revision A
DISASSEMBLY & ASSEMBLY Parts Diagram 104
Confidential
3.2 Parts Diagram
Refer to the pages indicated in brackets for the required disassembly/assembly procedure.
Figure 3-2. Housing 1
Control Panel Cover
(p136)
Left IC Cover Frame
(p140)
Front Cover
(p142)
Right Cover
(p139)
Left Cover
(p137)
Printer Cover
(p133)
Left Roll Cover
(p151)
Right IC Cover Frame
(p140)
Right Roll Cover
(p151)
CR Cover
(p149)
Media Eject Cover
(p148)
Right Upper Cover
(p138)
Rear Cover
(p144)
