Epson C11CA88001A1 Service Manual

Epson Stylus Pro 4900/Epson Stylus Pro 4910 Revision A
ADJUSTMENT CR Related Check & Adjustments 329
Confidential
4.10.7 Active Damper Adjustment
EXECUTION MODE
Normal Mode
PROCEDURE
1. When any paper is loaded, remove it.
2. Turn the printer ON.
3. Start the Service Program and select Active Damper Adjustment.
4. Click [Run] to execute the calibration of the CR active damper.
5. If Adjustment Successful appears, click [OK].
6. Click [Finish].
7. Turn the printer OFF to complete the adjustment.
Figure 4-34. Active Damper Adjustment
C H E C K
P O I N T
It takes about two minutes and 30 seconds to get the result of this
adjustment.
