Epson C11CA88001A1 Service Manual

Epson Stylus Pro 4900/Epson Stylus Pro 4910 Revision A
PRODUCT DESCRIPTION Hardware Specifications 26
Confidential
1.4 Hardware Specifications
This section provides the printer dimensions and shows the main components.
1.4.1 Dimensions and Weight
MAIN UNIT
Figure 1-3. Dimensions
Note *: Excluding the ink cartridges and paper
SPECTROPROOFER MOUNTER
Figure 1-4. Dimensions
Note *: Excluding the accessories and color measurement device.
構成 Width Depth Height Weight*
Body (with Paper Eject Support retracted) 863 mm 766 mm 405 mm Approx. 52 kg
Body (with Paper Eject Support extracted) 863 mm 1134 mm 405 mm Approx. 52 kg
Body & Color Measurement Device 877 mm 1299 mm 405 mm Approx. 60.7 kg
Height
Depth
Width
External Dimensions
Weight*
Width Depth Height
787 mm 199 mm 267 mm Approx. 9.0 kg
267 mm
199 mm
787 mm
