Epson Stylus Pro 4900/Epson Stylus Pro 4910 Revision A
ADJUSTMENT Overview 299
Confidential
4.1.4 Tools/Consumables for Adjustments
The tables below show the tools required for adjusting this printer.
Hardware Tools
Table 4-2. Hardware tools
Tool Name Part Number Target Adjustment Remarks
Sonic Tension Meter U-507
1294120
CR Belt Adjustment
PF Belt Adjustment
Cutter Belt Tension Check
---
P-Thick Sensor Position Jig
1424364
Paper Thickness Sensor Position
Adjustment
Use 0.5 mm tool of Epson Stylus Pro 7400.
Paper Thickness Position Tool
1282355
Use 0.4 mm and 0.8 mm tools of Epson Stylus Pro 4400.
PG Height Adjustment Jig 1.55
1543007
PG Height Check & Adjustment
---
PG Height Adjustment Jig 1.65
1507506
PG Height Adjustment Jig 1.75
1507277
Standard Sheet (JETRAS JP-D300S)
1476228
Rear AD Adjustment
---
Cleaning Cartridge
1537913
Tubes Cleaning
---
Tube + Mounting Plate
Create with
commercially
available items
Suction Check & Adjustment Create the measurement device with the commercially available items. (see p383)
Calibrated Loupe
Commercially
available
CR & PF Direction Head Slant
Adjustment
Cut Position Check & Adjustment
---
Ruler (about 10 cm)
Commercially
available
PW + T&B&S Check & Adjustment
Cut Position Check & Adjustment
To measures each type of patterns. 10 cm is enough to measure the patterns.
Color Measurement Device
---
Colorimetric Calibration Adjustment See p.342.
To Next Page
