Epson Stylus Pro 4900/Epson Stylus Pro 4910 Revision A
ADJUSTMENT Counter Reset 312
Confidential
4.7 Counter Reset
Whenever the parts/units which have life counter are replaced, the corresponding life
counter must be reset. This is important to replace those parts/units at the correct
timing.
PROCEDURE
1. Turn the printer ON.
2. Start the Service Program and click [FLAG CHANGE & COUNTER RESET]
from the main menu.
3. Click [Run] to reset the counter.
4. Click [Finish].
5. Confirm that the current counter value is [0].
Figure 4-16. [FLAG CHANGE & COUNTER RESET] Screen
Table 4-5. Clear Counter Menu List
Replaced Part/Unit Clear Menu Name
Printer
PF Motor PF Motor Counter
CR Motor CR Motor Counter
APG Motor Assy APG Motor Assy Counter
Roll Feeding Motor Assy
Roll Feeding Motor Counter
Roll Feeding Roller Counter
ATC Motor Assy ATC Motor Counter
Retard Roller Retard Roller Counter
Pickup Roller Pickup Roller Counter
Edge Release Assy Edge Release Assy Counter
Release Motor Assy Release Motor Assy Counter
ASF Motor Assy ASF Motor Assy Counter
ASF Sub Motor Assy ASF Sub Motor Assy Counter
Cutter Motor Assy Cutter Motor Assy Counter
IS Unit
Decompression Pump Counter
Wiper Counter (for Cleaning)
Wiper Counter (for Exchange)
Wiper Cleaner Counter
Head Cap Counter
IS Unit Counter
Wiper & Wiper Cleaner
Wiper Counter (for Cleaning)
Wiper Counter (for Exchange)
Wiper Cleaner Counter
Full (Left) Side Cartridge Holder Ink Holder Full Side (L) Counter
Home (Right) Side Cartridge Holder Ink Holder Home Side (R) Counter
Ink Selector Assy Ink Selector Assy Counter
Printhead Printhead Counter
Head FFC
FFC, Ink Tubes and CR Pads CounterInk Tubes
Oil pad holder
To Next Page
