Epson Stylus Pro 4900/Epson Stylus Pro 4910 Revision A
DISASSEMBLY & ASSEMBLY Disassembly and Assembly Procedure 145
Confidential
3.4.2.11 Rear Unit
1. Push the handles inward, and remove the Rear Unit.
Figure 3-44. Removing the Rear Unit
Rear Unit
Handles
