Epson C11CA88001A1 Service Manual

Epson Stylus Pro 4900/Epson Stylus Pro 4910 Revision A
PRODUCT DESCRIPTION Hardware Specifications 27
Confidential
1.4.2 Part Names
FRONT SIDE OF MAIN UNIT
Figure 1-5. Front side of Main Unit
BACK SIDE OF MAIN UNIT/SPINDLE
Figure 1-6. Back side of Main Unit/Spindle
Front cover
Cartridge
cover (left)
Paper cassette
Output tray
Maintenance Box 2
Paper eject
support
Front paper
feed slot
Cartridge
cover (right)
Maintenance Box 1
Ink cartridges
CR Unit
Control panel
Large alert light
Printer cover
Rear paper feed slot
Paper guide
Edge guide
Roll paper feed slot
Roll paper cover
Spindle holders
Rear unit
Roll paper holder
unit connector
USB interface
connector
Airflow
vent
LAN connector
AC inlet
Status light (green, red)
Movable flange (black)
Spindle
Attachment
Spacer
