Epson C11CA88001A1 Service Manual

Epson Stylus Pro 4900/Epson Stylus Pro 4910 Revision A
PRODUCT DESCRIPTION Control Panel 40
Confidential
 PG Settings List
The table below shows the actual platen gap amount specified by the printer driver
or the control panel.
Table 1-8. PG Settings List
Paper
Thickness
Sensor
Paper Thickness
Setting by Driver
Menu Setting
Media Table or Printer
Driver PG Setting
PG Value (mm)
Less than
0.4mm
No setting
0.0 to 0.8mm
Narrow
Narrow 0.8
Standard 0.8
Wide 1.2
Wider 1.6
Standard
Narrow 0.8
Standard 1.2
Wide 1.6
Wider 2.1
Wide
Narrow 1.2
Standard 1.6
Wide 2.1
Wider 2.6
Wider
Narrow 1.6
Standard 2.1
Wide 2.6
Wider 2.6
Widest
Narrow 2.1
Standard 2.6
Wide 2.6
Wider 2.6
0.9mm to 1.5mm -- -- 2.6
0.5mm to
0.8mm
No setting
0.0 to 0.8mm
Narrow
Narrow 1.2
Standard 1.2
Wide 1.2
Wider 1.6
Standard
Narrow 1.2
Standard 1.2
Wide 1.6
Wider 2.1
Wide
Narrow 1.2
Standard 1.6
Wide 2.1
Wider 2.6
Wider
Narrow 1.6
Standard 2.1
Wide 2.6
Wider 2.6
Widest
Narrow 2.1
Standard 2.6
Wide 2.6
Wider 2.6
0.9mm to 1.5mm -- -- 2.6
0.9mm to
2.1mm
-- -- -- 2.6
Table 1-8. PG Settings List
Paper
Thickness
Sensor
Paper Thickness
Setting by Driver
Menu Setting
Media Table or Printer
Driver PG Setting
PG Value (mm)
