Epson C11CA88001A1 Service Manual

Epson Stylus Pro 4900/Epson Stylus Pro 4910 Revision A
DISASSEMBLY & ASSEMBLY Disassembly Flowchart 118
Confidential
PAPER FEED MECHANISM
See “3.4.2.8 Front Cover (p142)”
See “3.4.2.3 Control Panel Cover
(p136)”
See “3.4.2.6 Right Cover (p139)”
See “3.4.2.15 CR Cover (p149)”
Start
See “3.4.5.9 Paper Thickness
Sensor1, 2 (p195)”
See “3.4.4.6 APG Motor Assy
(p179)”
( 左のみ )
See “3.4.2.1 Printer Cover (p133)”
See “3.4.2.4 Left Cover (p137)”
See “3.4.2.10 Rear Cover (p144)”
See “3.4.5.1 PF Motor (p182)”
See “3.4.2.4 Left Cover (p137)”
See “3.4.5.12 Edge Release Assy
(p199)”
See “3.4.5.2 PF Encoder (p183)”
See “3.4.5.10 Release Motor Assy
(p197)”
See “3.4.5.8 PW Sensor (p193)”
See “3.4.9.1 Ink Selector Assy
(p229)”
See “3.4.9.2 Printhead (p232)”
See “3.4.4.5 CR Unit/CR Belt
(p175)”
See “3.4.9.3 IS Unit (p233)”
See “3.4.5.13 Edge Sensor (p201)”
See “3.4.5.4 PF Belt (p185)”
See “3.4.5.3 PF Scale (p184)”
See “3.4.5.11 Release Sensor
(p198)”
See “3.4.5.5 Suction Fan (p186)”
See “3.4.2.14 Media Eject Cover
(p148)”
See “3.4.2.5 Right Upper Cover
(p138)”
See “3.4.1.1 Unlocking the CR
Unit (p124)”
See “3.4.2.10 Rear Cover (p144)”
See “3.4.5.6 PE Sensor (p188)”
See “3.4.2.11 Rear Unit (p145)”
See “3.4.5.7 2nd PE Sensor
(p192)”
See “3.4.2.16 Mid-Right Cover/
Mid-Left Cover (p150)” (L only)
