Epson C11CA88001A1 Service Manual

Epson Stylus Pro 4900/Epson Stylus Pro 4910 Revision A
DISASSEMBLY & ASSEMBLY Disassembly Flowchart 120
Confidential
ROLL UNIT
See “3.4.2.8 Front Cover (p142)”
See “3.4.2.5 Right Upper Cover
(p138)”
See “3.4.2.3 Control Panel Cover
(p136)”
Start
See “3.4.2.6 Right Cover (p139)”
See “3.4.2.17 Left Roll Cover/
Right Roll Cover (p151)”
See “3.4.7.5 Paper Guide Sensor
(p221)”
See “3.4.1.2 Roll Unit (p125)”
See “3.4.7.1 Roll Unit Sensor
(p216)”
See “3.4.2.14 Media Eject Cover
(p148)”
See “3.4.3.8 SUB-D Board
(p164)”
See “3.4.7.2 Roll Lock Sensor
(p217)”
See “3.4.7.3 ATC Motor Assy
(p219)”
See “3.4.7.4 Roll Feeding Motor
Assy (p220)”
See “3.4.7.6 Roll Feeding Sensor
(p222)”
See “3.4.2.4 Left Cover (p137)”
See “3.4.2.16 Mid-Right Cover/
Mid-Left Cover (p150)” (R only)
