Epson Stylus Pro 4900/Epson Stylus Pro 4910 Revision A
DISASSEMBLY & ASSEMBLY Parts Diagram 111
Confidential
Figure 3-9. Cutter Unit
Cutter Cover
(p223)
Cutter Unit
(p228)
Cutter Motor Assy
(p224)
Drives the Cutter. A DC motor with
an encoder scale mounted on it is
employed.
Cutter HP Sensor
(p226)
Detects the origin position
of the Cutter.
Cutter
(p127)
