Epson Stylus Pro 4900/Epson Stylus Pro 4910 Revision A
DISASSEMBLY & ASSEMBLY Disassembly and Assembly Procedure 172
Confidential
Attach the CR Scale with the marking on the top left corner.
Make sure to route the CR Scale through the detection part of
the CR Encoder Sensor on the rear of the CR Unit.
- Front left -
Marking
CR Scale
CR Encoder
Detection part
