Epson C11CA88001A1 Service Manual

Epson Stylus Pro 4900/Epson Stylus Pro 4910 Revision A
ADJUSTMENT Overview 282
Confidential
Carriage
Mechanism
CR Scale
1 CR Encoder and Scale Check Normal
√
--- ---
√√ p.327
2 CR Speed Initialize Normal
√
--- ---
√ p.328
CR Unit
1 FFC Position Check Normal
√
--- ---
√√ p.316
2 CR Belt Adjustment Normal
√
Sonic Tension Meter
U-507
---
√√ p.319
3 PG Height Check & Adjustment Normal
√
PG adjustment jig
1.55 mm/1.65 mm/
1.75 mm
---
√√ p.321
4 Nozzle Check Normal
√
--- Premium Glossy Photo Paper (250)
√√ p.334
5 CR Encoder and Scale Check Normal
√
---
√√ p.327
6 CR & PF Direction Head Slant Adjustment Normal
√
Calibrated loupe Premium Glossy Photo Paper (250)
√√ p.336
7 CR Speed Initialize Normal
√
--- ---
√ p.328
8 Active Damper Adjustment Normal
√
--- ---
√√ p.329
9 Ink Mark Sensor Check & Adjustment Normal
√
---
Enhanced Matte Paper A4
(ASF Feed)
√√ p.330
10 PW + T&B&S Check & Adjustment Normal
√
---
Enhanced Matte Paper A4
(ASF Feed & Rear Manual Feed)
√√ p.378
11 Auto Bi-D Adjustment Normal
√
--- Premium Glossy Photo Paper (250)
√√ p.341
Table 4-1. Adjustment items and the order by repaired part
Class Part/Unit Adjustment
Execution
Mode
Use of
SP
Jig Media RP RM Page
