Epson C11CA88001A1 Service Manual

Epson Stylus Pro 4900/Epson Stylus Pro 4910 Revision A
ADJUSTMENT Overview 288
Confidential
SpectroProofer
SpectroProofer Sensor 1 Spectroproofer Sensor Check Normal
√
--- ---
√√ p.401
SpectroProofer Drying
Fan
1 Spectroproofer Movement Check Normal
√
--- ---
√√ p.404
SpectroProofer
CR Motor
1
Counter reset after replacing the SpectroProofer
CR Motor
Normal
√
--- ---
√ p.312
2 Spectroproofer Movement Check Normal
√
--- ---
√√ p.404
3 Spectroproofer Measurement Precision Check Normal
√
--- ---
√√ p.406
SpectroProofer
Paper Pressing Motor
1
Counter reset after replacing the SpectroProofer
Paper Pressing Motor
Normal
√
--- ---
√ p.404
2 Spectroproofer Movement Check Normal
√
--- ---
√√ p.404
3 Spectroproofer Measurement Precision Check Normal
√
--- ---
√√ p.406
Main-C Board
(NVRAM Backup OK)
1 NVRAM Backup Normal
√
--- ---
√ p.302
2 Spectroproofer Serial Number Check & Input Normal √ --- --- √
p.408
Table 4-1. Adjustment items and the order by repaired part
Class Part/Unit Adjustment
Execution
Mode
Use of
SP
Jig Media RP RM Page
