Hioki 8841 - Setting the Status Screen; Setting the Channel Screen

79
────────────────────────────────────────────────────
5.4 Using the X-Y CONT Recorder
────────────────────────────────────────────────────
5.4.1 Setting the Status Screen
5.4.2 Setting the Channel Screen
Function
display
Meaning
:
Move the cursor up in the selection window.
:
Move the cursor down in the selection window.
:
Waveform is performed.
:
Waveform is not performed.
(1) Setting the format
1. Press the STATUS key to display the STATUS screen.
2. Move the flashing cursor to the
format item.
3. Use the function keys to make a setting. (See Section 5.3.5.)
(2) Setting the interpolation
1. Press the
STATUS key to display the STATUS screen.
2. Move the flashing cursor to the dot-line item.
3. Use the function keys to make a setting. (See Section 5.3.10.)
(3) Setting the display clearing
1. Press the STATUS
key to display the STATUS screen.
2. Move the flashing cursor to the
display clear item.
3. Use the function keys to make a setting. (See Section 5.3.11.)
Procedure
Screen: CHANNEL
1. Press the CHAN key to display the CHANNEL screen.
2. Press the CH.SET key to make a setting.
3. Move the flashing cursor to desired channel, and use the function keys to set
the display waveform on/off and waveform color.
4. Specify the X-axis channel.
Move the cursor to the channel to be used as X axis, and use the function
keys or the Jog/Shuttle control to select X axis.
5. Specify the Y-axis channel.
This is done in the same way as the X-axis setting.
6. For graph 2 to graph 4, the settings are made in an identical.
