Chapter 7
Recorder & Memory Function
7.1 Overview of the Recorder & Memory Function
The recorder and memory function has the following features.
(1) After being stored in the internal memory, input signal data can be displayed
and printed.
(2) All input channel data are recorded on the same time axis.
Since data for all channels can be superimposed, the relative relationship
between input signals can be observed visually.
(3) Time axis setting
20 ms/DIV to 1 h/DIV (recorder, 16 steps)
100
μ
s/DIV to 5 min/DIV (memory, 20 steps)
(4) Time axis resolution 100 points/DIV
(5) Storage capacity
8 M words (DIV) 1000 (Recorder) 2000 (Memory)
32 M words (DIV) 5000 (Recorder) 10000 (Memory)
(6) Display format
Single, dual, quad, oct screen display (LCD), hex screen display (when
printing)
(7) Printing
Real-time print (recorder only), manual print, partial print, report print,
screen hard copy can be printed.
(8) High-quality print
Smooth print function approximates analog waveform.
(9) Additional recording function
The first set of measurement data is preserved, and recording of the second
set of measurement data starts after the first set.
(10) Logging function
Numeric printout of waveform data
