7.3 STATUS Settings (REC&MEM)
────────────────────────────────────────────────────
Function
display Meaning
:
Increases in number.
:
Decreases in number.
NOTE
7.3.4 Display Function
Function
display
Meaning
:
Memory waveform is displayed
:
Recorder waveform is displayed
NOTE
Procedure 2 Variable recording length mode
1. Use the Menu keys to display the desired screen.
2. Move the flashing cursor to the
shot
item.
3. To set the recording length, move the flashing cursor to either Recorder or
Memory, according to which is to be set, and select ARBITRARY.
4. Use the Jog/Shuttle control or the function keys to make a setting. To
change the column, use the cursor keys ( ).
･
If the recording length is changed during measurement, measurement is
restarted using the newly set recording length.
･
When the recording length of the recorder is set to "CONT.", the auto-saving
function is automatically set to off.
･
The memory capacity of 8 M words can accommodate up to 1000 divisions
(recorder) or 2000 divisions (memory) of waveform data. With 32 M words,
waveform data of up to 5000 divisions (recorder) or 10000 divisions
(memory) can be saved.
･
In fixed-length recording mode, the symbol "*" in the selection window
indicates the recording length of the data stored to current memory. (If no
data is present in memory, this symbol is not displayed.) In any recording-
length mode, the symbol "#" is displayed before the recording length.
The type of display waveform can be selected.
During measurement, the recorder waveform is displayed.(automatically set
to recorder)
Procedure
Screen: STATUS1
1. Press the STATUS key to display the STATUS1 screen.
2. Move the flashing cursor to the function item.
3. Use the function keys to make a setting.
･
The type of display waveform can be set by pressing the REC&MEM
function key on the Waveform display screen.
･
The memory waveform in Recorder and Memory function can be also
displayed in memory recorder function.
