4.3 ST ATUS Settings (MEM)
────────────────────────────────────────────────────
4.3.9 Setting the Auto Save Function
Function
display
Meaning
:
Auto save is disabled.
:
Automatically stored on floppy disk
:
Automatically stored on PC card.
:
Automatically stored on connected SCSI device.
:
Automatically stored on MO disk.
:
(When using a LAN card)
A LAN is used to transfer data to the 9333 LAN COMMUNICATOR.
Function
display
Meaning
:
When the media becomes full, automatic storage stops.
:
When the media becomes full, old files are deleted to make room for
automatic storage.
With the binary format selected, the file with the extension 'MEM' is
deleted, and if sequential save is selected, files with the extension
'SEQ' are also deleted. With the text format selected, files with the
extension 'TXT' are deleted.
Function
display
Meaning
:
Data are stored as binary data.
:
Dataarestoredastextdata.
Function
display
Meaning
:
Move the cursor up in the selection window.
:
Move the cursor down in the selection window.
When the function is enabled, measurement data are automatically stored on
a floppy disk, PC card, MO disk or connected SCSI device after they are
captured. The Auto Save function stores a file in the directory currently
selected on the file screen. See Section 14.12.2.
Procedure
Screen: STATUS1
1. Press the
STATUS
key to display the STATUS1 screen.
2. Move the flashing cursor to the
auto save
item.
3. Use the function keys, select the media for auto saving.
4. When Media is selected, the Storage method item appears.
5. Move the flashing cursor to
type
, and select the format.
Data stored in the text format is not readable by the 8841/42.
6. When the data format to be saved is set to text data, the intermittent setting
item is displayed. Use the function keys or Jog/Shuttle control to make a
setting.
