8.4 STATUS2 Settings (FFT)
────────────────────────────────────────────────────
8.4.5 Setting the Auto Save Function
Function
display
Meaning
:
Auto save is disabled.
:
Automatically stored on floppy disk
:
Automatically stored on PC card.
:
Automatically stored on connected SCSI device.
:
Automatically stored on MO disk.
:
(When using a LAN card)
A LAN is used to transfer data to the 9333 LAN COMMUNICATOR.
Function
display
Meaning
:
When the media becomes full, automatic storage stops.
:
When the media becomes full, old files are deleted to make room for
automatic storage.
With the binary format selected, the file with the extension 'FFT' is
deleted.
With the text format selected, files with the extension 'TXT' are
deleted.
Function
display Meaning
:
Data are stored as binary data.
:
Dataarestoredastextdata.
The FFT analysis is carried out and measurement data are automatically
stored on a floppy disk, PC card, MO disk or connected SCSI device after
they are captured. The Auto Save function stores a file in the directory
currently selected on the file screen. See Section 14.12.2.
Procedure
Screen: STATUS2
1. Press the
STATUS
key to display the STATUS2 screen.
2. Move the flashing cursor to the auto save item.
3. Use the function keys, select the media for auto saving.
4. When Media is selected, the Storage method item appears.
5. Move the flashing cursor to type, and select the format.
Data stored in the text format is not readable by the 8841/42.
6. Set the file name. For the input method, refer to Section 9.9.3.
When using auto-save, a number is appended to the name you specify as the
file name. This then becomes the file name. If you start procedures before
specifying a file name, AUTO is automatically enabled.
File names cannot contain the characters +, -, ], or [. Please note that file
names containing these characters will not be saved.
