18.4 Memory Recorde r Function
────────────────────────────────────────────────────
Time axis
100, 200, 500
μ
s/DIV
1, 2, 5, 10, 20, 50, 100, 200, 500 ms/DIV
1, 2, 5, 10, 30 s/DIV
1, 2, 5 min/DIV
EXT.
Time axis resolution
100 points/DIV
Sampling period
1/100 of the time axis
Recording length
Standard (8 M words)
25,50,100,200,500,1000,2000,5000,10000
*1,
20000
*2,
40000
*3
DIV
Expansion (32 M words)
25,50,100,200,500,1000,2000,5000,10000,20000,40000
*1,
80000
*2
,160000
*3
DIV
Arbitrarily (Set from 1 division to the maximum number of divisions at 1-
division intervals.)
Screen/print format
The styles single, dual, quad, oct (LCD) / hex
（
Print only), X-Y single /
X-Y dual (dot/line) are available.
Interpolation
Line
（
excluding X-Y format
）
,Dot
･
line
（
X-Y format
）
Recording line display
12-color
（
LCD
）
, Printout: 4-type
Overlay function
Provided
Waveform magnification/
compression
Time axis
×
10,
×
5,
×
2,
×
1,
×
1/2,
×
1/5,
×
1/10,
×
1/20
、×
1/50,
×
1/100,
×
1/200, 1/500,
×
1/1000,
×
1/2000,
×
1/5000,
×
1/10000
Measurement range
×
10,
×
5,
×
2,
×
1,
×
1/2
（
single, X-Y single
）
×
5,
×
2.5,
×
1,
×
1/2,
×
1/4
（
2, 4, 8, 16, X-Y single/ dual
）
Waveform scrolling
Available in the left/right directions
Auto-print
Automatically prints the memorized waveform
Manual print
Available
Partial print
Prints between the A and the B cursors
Print smoothing function
When set, a smoothed waveform is printed, with twice the density in the
time axis direction.
A4 print
Available
Logging function
Records measured data as digital values
Variable function
Provided
Zoom function
Provided
18.4 Memory Recorder Function
（
*1
）: When 8 channels are in use
（
*2
）: When 4 channels are in use
（
*3
）: When 2 channels are in use
