9.11 Setting the 8937 VOLTAGE/TEMP UNIT
────────────────────────────────────────────────────
9.11.2 Making the Settings of Temperature Measurement
Flashing cursor
Function
display
Meaning
:
Move the cursor up in the selection window.
:
Move the cursor down in the selection window.
TMP
Measurement
range
TMP
Measurement
range
K
E
J
T
-200
o
Cto1350
o
C
-200
o
C to 800
o
C
-200
o
Cto1100
o
C
-200
o
C to 400
o
C
N
R
S
B
-200
o
Cto1300
o
C
0
o
Cto1700
o
C
0
o
Cto1700
o
C
300
o
Cto1800
o
C
Flashing cursor
Function
display
Meaning
:
Move the cursor up in the selection window.
:
Move the cursor down in the selection window.
Function
display
Meaning
:
Drift compensation is enabled.
:
Drift compensation is disabled.
Select the thermocouple type, drift correction and standard contact
compensation to be used.
Procedure
Screen: CHANNEL,Waveform display
(1) Set the measurement mode.
1. Display the CHANNEL or Waveform display screen.
2. Press the
CH.SET key to display the channel screen to
be set.
3. Move the flashing cursor to the unit item. Use the
function keys, or Jog/Shuttle control to select TMP
(temperature).
(2) Set the measurement range and Drift compensation.
Drift compensation is a function that periodically
(about once per second) cancels the variances in the
reference voltage that accumulate over time.
1. Move the flashing cursor to the position shown in the
figure on the left.
2. Use the function keys or the Jog/Shuttle control to set
the measurement range.
3. Use the function keys to set the drift compensation.
