Hioki 8841 - Chapter 11 Waveform Display Screen Operation

245
────────────────────────────────────────────────────
────────────────────────────────────────────────────
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
Setting the Input channel
To set a numerical value using the Jog/Shuttle control
on the Waveform display screen, press the VALUE
select key.
（
The selection window is not displayed.)
Pressing the CH.SET key, enables the measurement
conditions for each channel on the Waveform display
screen to be set or changed.
See Section 9.10
.
Scrolling the Waveform
To scroll the waveform on the Waveform display
screen, press the WAVE select key.
Use the Jog/Shuttle control to scroll the waveform.
Usin
g
the A
･
BCursors
When want to use the A
･
B Cursors, press the A
･
B CSR
select key.
Magnification/compression
MEM, memory waveform in REC&MEM:
ratio along the time axis
magnification and compression
REC, RMS, recorder waveform in REC&MEM:
compression only
Zoom function
This function divides the memory recorder function
Waveform display screen into upper and lower
windows, so that the regular-size waveform is
displayed in the upper window and the waveform
enlarged in the time axis direction is displayed in the
lower window.
Input level monitor
Press the LEVEL MONI key on the Waveform display
function
screen, waveform input level can be monitored.
View function
Pressing the VIEW key shows the position of the
currently displayed waveform within the entire
recording length, and shows the memory segmentation
status.
Line cursor (vertical)
Line cursor (horizontal)
Trace cursor
Chapter 11
Waveform Display Screen
Operation
Indicates the Waveform display screen operation.
