169
────────────────────────────────────────────────────
9.3 Setting the CHA NNEL Screen
────────────────────────────────────────────────────
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
9.3.1 Setting the Waveform Display Color
Function
display Meaning
:
Move the cursor up in the selection window.
:
Move the cursor down in the selection window.
:
When outputting data with the internal printer,
you may set for line type. (See Section 13.3.1)
:
Waveform is performed.
:
Waveform is not performed.
9.3.2 Setting the Waveform Display Graph Position
Function
display Meaning
:
Move the cursor up in the selection window.
:
Move the cursor down in the selection window.
NOTE
Set the display color for the waveform.
Procedure
Screen: CHANNEL,Waveform display
1. Use the Menu keys to display the desired screen.
2. Press the CH.SET key to display channel to be set.
3. Move the flashing cursor to color item. (col on the CHANNEL screen)
4. Use the function keys or Jog/Shuttle control to make a setting.
Sets the position at which the waveform is displayed. The waveform display
position can be set when settings other than Single screen are selected in
Display format setup on STATUS screen.
Procedure
Screen: CHANNEL,Waveform display
1. Use the Menu keys to display the desired screen.
2. Press the
CH.SET key to display channel to be set.
3. Move the flashing cursor to graph item.
4. Use the function keys or Jog/Shuttle control to make a setting.
For the X-Y screen (memory recorder and recorder) display format, see the
X-Y recorder setting for each function.
