7.3 STATUS Settings (REC&MEM)
────────────────────────────────────────────────────
NOTE
7.3.8 Setting the Printer Function (Real-time Printing)
Function
display Meaning
:
Printing is disabled.
:
Printing is enabled.
NOTE
･
Time values output to the printer and displayed on the screen with the
additional recording function enabled are equal to those of the most recently
acquired waveforms. Therefore, when measuring waveforms in a different
time axis range, always take that difference into consideration.
･
When the 1000 (32 M words: 5000) DIV has been reached, old data will be
overwritten.
･
In the recorder, the trigger mark ( ) is written as the start position mark. In
an additional recording, the trigger mark is displayed in front of the most
recently entered data.
･
If auto-save is enabled, only newly acquired waveforms are saved. Even
when A and B cursors appear on the screen, no partial save is performed,
because the setting is disabled when the START
key is pressed.
The input waveform (recorder waveform) is continuously printed in real
time.
Procedure
Screen: STATUS1
1. Press the STATUS key to display the STATUS1 screen.
2. Move the flashing cursor to the printer item.
3. Use the function keys to make a setting.
･
When the recorder's time axis is set to 200 ms/DIV or faster, the printer
settings are automatically disabled.
･
While the printer always outputs the data at the measurement magnification
in recording mode, the waveform on the screen is reduced in size at the ratio
shown in the table below, depending on the time-axis range.
100 ms/DIV
×
1/2, 50 ms/DIV
×
1/5, 20 ms/DIV
×
1/10
