106
────────────────────────────────────────────────────
7.3 STATUS Settings (REC&MEM)
────────────────────────────────────────────────────
7.3.6 Setting the Print Mode
Function
display Meaning
:
Measurement data and the result of calculation
are printed as a waveform.
:
Measurement data and the result of calculation
are printed as numeric data.
NOTE
Select the format, waveform, or numerical value should be used to output
measured data and calculation results.
Waveform
The smooth print function can be used, but print speed will
decrease.
Numerical value
The data spacing interval also must be set.
Procedure
Screen: STATUS1
(1) Setting the printer format
1. Press the
STATUS
key to display the STATUS1 screen.
2. Move the flashing cursor to the print mode item.
3. Use the function keys to make a setting.
(2) Setting the smooth printing and print interval
1. When the waveform format is selected, determine whether to use the smooth
printing or not. When the numerical value is selected, set the print interval.
(unit: divisions)
2. Move the flashing cursor to the smooth print item or interval.
3. Use the function keys to make a setting.
Since 1 division represents 100 samples, the print interval "0.01" refers to a
printout of every sample (no print interval). If the set print interval exceeds
recording length, only the first point is printed.
Smooth printing is available for memory waveform.
