9.10 Setting the Waveform Display Screen
────────────────────────────────────────────────────
9.10.1 Entering by CH.SET Key
Waveform display screen
Setting the analog
channel 1 to 16
Setting the variable
and full-span for
channel 1 to 16
Setting the logic
channel A to D
OFF
Press the CH.SET ke
y
,to
gg
le the in
p
ut screen.
NOTE
9.10 Setting the Waveform Display Screen
Pressing the
CH.SET
key, enables the measurement conditions for each channel on
the Waveform display screen to be set or changed.
It is possible to make the settings, while monitoring the waveforms in real time on
the Waveform display screen. For details on settings, refer to Section 9.3.
Setting the analog channels
・Waveform display color
・Waveform display graph position
・Unit name
・Measurement range
・Magnification/compression ratio, Vernier function
・Zero position
・Low-pass filter
・Full span
（Channel copy can not be carried out）
Setting the full span /variable
・Full span
・Variable function
(can not be set to ON/OFF)
Setting the logic channels
・Waveform display color
・Waveform display graph position
In FFT function, the
CH.SET
key cannot be used to input.
