6.3 ST ATUS Settings (RMS)
────────────────────────────────────────────────────
6.3.6 Setting the Print Mode
Function
display Meaning
:
Measurement data and the result of calculation
are printed as a waveform.
:
Measurement data and the result of calculation
are printed as numeric data.
Function
display
Meaning
:
Move the cursor up in the selection window.
:
Move the cursor down in the selection window.
NOTE
Select the format, waveform, or numerical value should be used to output
measured data.
Waveform
The waveform is printed.
Numerical value
The data spacing interval also must be set.
Procedure
Screen: STATUS
(1) Setting the printer format
1. Press the
STATUS
key to display the STATUS screen.
2. Move the flashing cursor to the print mode item.
3. Use the function keys to make a setting.
(2) Setting the print interval
1. When the numeric data is selected in step (1), set the print interval.
2. Move the flashing cursor to interval.
3. Use the function keys to make a setting.
Since each division equals 100 samples, the print interval "0.01" indicates
one sample (no print interval).
When the print interval longer than the recording length is set, only the first
dot is printed.
･
The maximum and minimum values are printed (excluding 5 s/DIV).
See Appendix 3.5.
･
The print intervals of 0.01 to 0.5 DIV can be selected, only when there are
waveform data present.
･
When numerical values are output for real-time printing, the minimum print
interval is 1 division.
