269
────────────────────────────────────────────────────
12.5 INTERFACE Screen (SYSTEM 4)
────────────────────────────────────────────────────
12.5.1 Output Destination by the COPY Key
NOTE
12.5.2 Output Destination by the PRINT Key
NOTE
12.5.3 Interface Settings
NOTE
The screen data output destination when the
COPY
key is pressed and the the
color of the output destination can be specified.
･ When the output destination is specified other than internal and external
printers and the color of output destination is set to monochrome, the screen
is displayed in monochrome while data saving is in progress.
･ Stores a file in the directory currently selected on the file screen. See Section
14.12.2.
The measurement data output destination when the
PRINT key is pressed and
the color of the output destination can be specified.
Even if the information that has been input using the PRINT key is to be
output to the external printer, automatic printing or real-time printing is
performed on the internal printer rather than the external printer.
When the GP-IB interface, RS-232C interface, or LAN interface is used, the
following items must be set.
GP-IB
Mode ADDRESSABLE / TALK ONLY / DISABLE
Address 0 to 30
Header OFF/ON
RS-232C
Transfer rate 1200/ 2400/ 4800/ 9600/ 19200/ 38400/ 57600/ 115200
Data word length 8 bit/ 7 bit
Parity NONE/ EVEN/ ODD
Stop bit 1 bit/ 2 bit
Delimiter LF/ CR＋LF
Header OFF/ ON
Flow control NONE/ Xon/Xoff/ HARD
LAN
Refer to Section 12.5.6, "Setting the LAN
For details, refer to the "9558 GP-IB CARD" or "9557 RS-232C CARD"
Instruction Manual.
To Next Page
