Hioki 8841 - Chapter 4 Memory Recorder Function; Overview of the Memory Recorder Function

37
────────────────────────────────────────────────────
4.1 Overview of the Memory Recorde r Function
────────────────────────────────────────────────────
1
2
3
4
5
6
7
8
9
10
11
12
13
14
A
1
2
3
4
5
6
7
8
9
10
11
12
13
14
A
Number of channels 16 8 4 2
8 M words (DIV)
32 M words (DIV)
5000
20000
10000
40000
20000
80000
40000
160000
Chapter 4
Memory Recorder Function
4.1 Overview of the Memory Recorder Function
The memory recorder function has the following features.
(1) After being stored in the internal memory, input signal data can be displayed
and printed.
(2) All input channel data are recorded on the same time axis.
Since data for all channels can be superimposed, the relative relationship
between input signals can be observed visually.
(3) Time axis setting
100 μs/DIV to 5 min/DIV
(4) Time axis resolution 100 points/DIV
(5) Storage capacity
(6) Waveform magnification/compression display and print
・Time axis direction ×10 to ×1/10000 (16 steps)
・Voltage axis direction ×10 to×1/2 (single),×5to×1/4 (2 to 8, X-Y single,
dual screens) 5 steps
・With the variable function, vernier function, zoom function
(7) Display format
・Time axis waveform: single, dual, quad, oct screen display (LCD), hex
screen display (when printing)
・X-Y waveform: single, dual screen display (dot, line)
(8) Printing
・Auto print, Manual print, Partial print, Report print, Screen hard copy.
・Multiple printing possible.
(9) High-quality print
Smooth print function approximates analog waveform.
