13.4 Setting the SYSTEM Screen (printout)
────────────────────────────────────────────────────
0 position
Comment
Function
display
Meaning
:
0 position comment is not used.
:
0 position comment is used.
Counter Print
Function
display Meaning
gc-pr6, 7
:
Counter Print is not printed.
:
Counter Print is printed with date.
:
Counter Print is printed with counter name.
13.4.2 SCALING Screen (SYSTEM 2)
NOTE
13.4.3 COMMENT Screen (SYSTEM 3)
NOTE
In waveform printing, comments are printed out in the zero position of each
channel. This comment printing is valid only for the analog channels.
Comments can be set on SYSTEM3 (COMMENT) screen.
In waveform printing, the counter can be printed out. This function is useful
to distinguish between similar waveforms.
・A counter name of up to ten characters can be specified. For information on
how to enter the counter name, see Section 9.9.3.
・After the unit is turned on, the counter is reset to 0 (zero), and the counter
value is increased each time a waveform is retrieved. (The maximum
counter value is 9999.) To initiate waveform acquisition from an arbitrary
count value, move the flashing cursor to the counter-value entry field and
specify the desired value using the function keys or the Jog/Shuttle control.
・The scaling function can be used to convert an output voltage from a sensor
or similar into a physical quantity.
・Two types of scaling functions are available.
・The gauge scale (maximum and minimum values of vertical axis) and A･B
cursor measurement values are displayed in the scaled units.
・Scaling can be performed for every channel.
For details, see Section 9.8.
Three types of comment are available.
If "COMMENT" or "SET & COM" is selected, this comment will be
included on the recording paper in all functions.
For details, see Section 9.9.
