6.5 Start and Stop Operation (RMS)
────────────────────────────────────────────────────
Trigger mode: SINGLE
REPEAT
Setting the 8841/42
･
STATUS Settings
･
Channel Settings
･
Trigger Settings
Trigger condition
are met
Measurement start
Recording start
Recording end
Measurement end
6.5 Start and Stop Operation (RMS)
See Section 6.3, "STATUS Settings", Chapter 9, "Input Channel
Settings", Chapter 10, "Trigger Functions."
Press the START key and LED light.
When the trigger can be registered, the indication "Waiting for
trigger" is shown on the display.
Data recording starts when trigger condition are met.
Displays "Storing".
If the printer is on, printing initiates simultaneously with
display.
Using the VIEW key to display the time (from measurement
started time).
When automatic storage is enabled and measurement is
interrupted in progress, measurement data taken prior to the
interruption point is stored automatically.
Auto save are executed.
End of measurement
Each time when trigger conditions are met, data are recorded
and memory contents are overwritten.
When the STOP key is pressed, measurement stops after data
corresponding to recording length have been stored in memory.
(auto save are not executed.)
