7.3 STATUS Settings (REC&MEM)
────────────────────────────────────────────────────
7.3.9 Setting the Auto Save Function
Function
display Meaning
:
Auto save is disabled.
:
Automatically stored on floppy disk
:
Automatically stored on PC card.
:
Automatically stored on connected SCSI device.
:
Automatically stored on MO disk.
:
(When using a LAN card)
A LAN is used to transfer data to the 9333 LAN COMMUNICATOR.
Function
display Meaning
:
When the media becomes full, automatic storage stops.
:
When the media becomes full, old files are deleted to make room for
automatic storage.
When 1 Block Save is selected with the Binary Format, the memory
waveforms with the file extension 'MEM' are deleted. If sequential save is
selected, files with the extensions 'SEQ' and 'MEM' are deleted, and the
recorded waveforms in the 'REC' file is deleted.
When All Block Save is selected with the Binary Format, files with the
extensions 'R-M', 'MEM' and 'REC' are deleted.
With the text format selected, files with the extension 'TXT' are deleted.
Function
display Meaning
:
Data are stored as binary data.
:
Dataarestoredastextdata.
Function
display Meaning
:
Move the cursor up in the selection window.
:
Move the cursor down in the selection window.
When the function is enabled, measurement data are automatically stored on
a floppy disk, PC card, MO disk or connected SCSI device after they are
captured and the recording is completed. The Auto Save function stores a
file in the directory currently selected on the file screen. See Section
14.12.2.
Procedure
Screen: STATUS1
1. Press the STATUS key to display the STATUS1 screen.
2. Move the flashing cursor to the auto save item.
3. Use the function keys, select the media for auto saving.
4. When Media is selected, the Storage method item appears.
5. Move the flashing cursor to type, and select the format.
Data stored in the text format is not readable by the 8841/42.
6. When the data format to be saved is set to text data, the intermittent setting
item is displayed. Use the function keys or Jog/Shuttle control to make a
setting.
