13.6 Printing Procedure
────────────────────────────────────────────────────
13.6.2 Auto Print
s1162
NOTE
Printout is carried out automatically after a waveform has been captured for
the specified recording length. (MEM, FFT)
Procedure
Screen: STATUS1 (MEM), STATUS2 (FFT)
1. Press the STATUS key to display the
STATUS1(STATUS 2 in FFT) screen.
2. Move the flashing cursor to the auto print item.
3. Use the function keys, and select IN-PRINTER.
When COMMUNI is selected, a LAN is used to
transfer printing images to the 9333 LAN
COMMUNICATOR.
4. Press the START key to start the measurement.
Printout is carried out automatically after a waveform
has been captured for the specified recording length.
･ When cursors A and B are enabled in memory
recorder function, partial printing is executed .
･ When the roll mode is enabled in memory recorder
function and the time-axis range is lower than 10
ms/division, data is displayed and printed
simultaneously.
･ When both auto-print and auto-save are enabled in
memory recorder function, auto-save usually takes precedence. However, if roll mode is enabled,
auto-print will execute first.
