4.3 ST ATUS Settings (MEM)
────────────────────────────────────────────────────
4.3.12 Setting the Waveform Evaluation
NOTE
･ Display format can be set on single screen or X-Y single screen.
･ GO (pass) or NG (fail) evaluation of the input signal waveform can be
performed using an evaluation area specified by the user. This can serve to
detect irregular waveforms. After the evaluation result is generated, signals
are output from the GO/NG terminal. All the channels being displayed are
evaluated.
･ When a waveform evaluation area is created by the memory recorder
function, the waveform evaluation area created by the FFT function is
cleared.
･ For details on the waveform evaluation, refer to Section 16.3.
